Electric transfer cart is also known as electric flat cart, which is a kind of electric rail transportation car that are widely used in factories and plants. Transfer cart is a rail type transportation vehicle, and users need to lay rail tracks on the ground that is generally H-shaped contact rail in advance. Battery transfer cart can work automatically under the motivation of electricity, which is a flat car that has no cover or steeling wheel. Rail transfer cart has simple structure, easy operation, large carrying capacity, strong dirty and pressure resistance, easy maintenance and long service life.
Industrial transfer cart has become a preferred vehicle that is used inside the plant or short distance transportation between plats because of its convenience, economy, practicability and availability. Heavy duty flat cart is mainly applied to movable lifting water blank car, brickyard, refractory factory, ceramics factory and electric sanitation removal trucks. Moreover, pullet transfer carts are also used in mill plant, concentrating mill, casting factory, chemical factory, furnace charge factory, farms and so on.
Hengyuan Group has engaged in the innovation and production of heavy goods transferring and lifting equipment for over 30 years, and our hot products includes transfer trolley, overhead crane, double girder gantry crane, hoist, die transfer cart etc. Being a well-known transfer carts manufacturer, our transfer cart for sale overpasses other manufacturers in transfer cart price and quality with CE, ISO, and SGE recognition. If you want to know our transfer cart line items, please feel free to contact us at any time.
Features and Advantages:
It has high anti-explosion and anti-high temperature performance.
Electric transfer cart has no strict requirement for the construction of the railway.
It has safe and flexible movement, which is also convenient to use.
The running speed of the electric transfer carts can be adjusted with actual situation.
Product Parameter:
| Model |
KPX-2t |
KPX-20t |
KPX-50t |
KPX-100t |
KPX-150t |
| Rated Load(t) |
2 |
20 |
50 |
100 |
150 |
| TableSize(mm) |
Length(L) |
2000 |
4000 |
5500 |
6500 |
10000 |
| Width(W) |
1500 |
2000 |
2500 |
2800 |
3000 |
| Heigth(H) |
450 |
550 |
650 |
850 |
1200 |
| Wheel Base(mm) |
1200 |
2800 |
4200 |
4900 |
7000 |
| Rail Inner Gauge(mm) |
1200 |
1435 |
1435 |
2000 |
2000 |
| Wheel Diameter(mm) |
270 |
350 |
500 |
600 |
600 |
| Wheel Quantity |
4 |
4 |
4 |
4 |
8 |
| Ground Clearance(mm) |
50 |
50 |
50 |
75 |
75 |
| Running Speed(mm) |
25 |
20 |
20 |
20 |
18 |
| Motor Power(kw) |
0.8 |
2.5 |
5.5 |
11 |
15 |
| Max Wheel Load(KN) |
14.4 |
77.7 |
174 |
343.8 |
265.2 |
| Reference Weight(t) |
2.3 |
5.5 |
7.6 |
13.9 |
26 |
| Recommended Rail Model |
P15 |
P24 |
P43 |
QU100 |
QU100 |
Schematic Drawing:
