portal crane

Portal crane for port are state-of-the-art, economical and flexible handling machines on rails. They are based on the well proven mobile harbour crane technology and can be easily integrated into existing or planned terminal infrastructures.

Product catalog

send email

Get a quote

Share With:

Product Description

Portal crane for port are state-of-the-art, economical and flexible handling machines on rails. They are based on the well proven mobile harbour crane technology and can be easily integrated into existing or planned terminal infrastructures. Their strengths: Use on special-purpose quays for tough continuous-duty bulk handling Possibility of providing specific portal solutions in line with terminal requirements Modular construction Comparatively low total weight.

Single Boom Shipyard Crane ensures safety for operators even in harsh weather. HYCranes Single Boom Shipyard Cranes are the right choice for general ship outfitting. They can be used in small and large shipbuilding and repair. With the latest design enhancements from HYCranes, they can be made rigid for heavier loads.

Advantage:

1.Automatic rectify deviation control
2.Weight overload protection device
3.Top quality polyurethane buffer
4.Phase protection
5Lifting limit switch
6.Cross traveling limit switch
7.Long traveling limit switch
8.Voltage lower protection function
9.Emergency stop system
10.Current overload protection system
11.Lighting system
12.Light and alarm system

SWL(Kg)	Span (m)	Lifting Height (m)	Crab Travel(m/min)	Lifting Speed (m/min)	Steering mode	Steering angle
5000+5000 (2m)	12	6/9	10/15/20m/min	8, 8/0.8 Standard Speed	Hydraulic-2 Hydraulic-4
	16
	20
10000+10000 (2m)	12	6/9		7, 7/0.7 Standard Speed
	16
	20
20000+20000 (2m)	12	6/9		3.5, 3.5/0.35 Standard Speed
	16
	20
32000+32000 (1Am)	12	6/9		3.5, 3.5/0.35 Standard Speed
	16
	20
50000+50000 (1Am)	12	6/9		4 Standard Speed
	16
	20

Application

Company advantages

	Hengyuan crane--Powerful
13 years of industry experience, with more than 500 modern production and testing equipment (sets), more than 650 employees, including experienced professional and technical personnel and more than 160 management talents who are well versed in the way of business.
	Hengyuan crane--International Certification
The company has successively passed the GB/T19001-2008/ISO9001:2008 international quality management system, GB/T24001-2004/ISO14001:2004 environmental management system, and GB/T28001-20011/OHSAS18001:2007 occupational health and safety management system certification.

Company strength

As a top crane innovation and production company, we not only offer top-quality crane for sale, but also provide reasonable purchase suggestion, safe crane package and professional installation guidance for worldwide customers. With the approval of SGS, CE and ISO certification, there is no doubt that our crane has reliable quality, wide application, standard performance and long lifespan.

Factory tour


Production site	Loading moment	Function Room

Product ready to ship	Staff canteen	Transport loading
